QUANTA LB4M - Match Srcl4 Port; Match Vlan

UANTA COMPUTER INC.
Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 377/970
None
Command Mode
Class-Map Config
6.18.2.20 match srcl4port
This command adds to the specified class definition a match condition based on the source
layer 4 port of a packet using a single keyword or numeric notation or a numeric range notation.
Syntax
match srcl4port {<portkey> | <0-65535>}
<portkey> is one of the supported port name keywords (listed below).
The currently supported <portkey> values are: domain, echo, ftp, ftpdata, http, smtp, snmp,
telnet, tftp, www. Each of these translates into its equivalent port number, which is used as
both the start and end of a port range.
To specify the match condition as a numeric value, one layer 4 port number is required. The
port number is an integer from 0 to 65535.
To specify the match condition as a range, two layer 4 port numbers are required and together
they specify a contiguous port range. Each port number is an integer from 0 to 65535, but with
the added requirement that the second number be equal to or greater than the first.
Default
None
Command Mode
Class-Map Config
6.18.2.21 match vlan
This command adds to the specified class definition a match condition based on the value of
the layer 2 VLAN Identifier field (the only tag in a single tagged packet or the first or outer tag of
a double VLAN tagged packet). The VLAN ID is an integer from 1 to 4095.
NOTE: This command is not available on the Broadcom 5630x platform.
