Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 779/970
11.2.3 Routing Menu
11.2.3.1 Managing ARP Table
11.2.3.1.1. Creating ARP entries
Use this panel to add an entry to the Address Resolution Protocol table.
Configurable Data
IP - Specifies all the existing static ARP along with an additional option "Create". When
the user selects "Create" another text boxes " IP Address" and "MAC Address" appear
where the user may enter IP address and MAC address to be configured.
IP Address - Enter the IP address you want to add. It must be the IP address of a device
on a subnet attached to one of the switch's existing routing interfaces.
MAC Address - The unicast MAC address of the device. Enter the address as six
two-digit hexadecimal numbers separated by colons, for example 00:06:29:32:81:40.
Command Buttons
Submit - Update the switch with the values on this screen. If you want the switch to retain
the new values across a power cycle, you must perform a save.
Delete - Allows the user to remove specified static entry from the ARP Table.
Delete All - Allows the user to remove all static entries from the ARP Table.
