Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 48/970
. The console port is set for the following configuration:
. Baud rate: 11,520
. Data width: 8 bits
. Parity: none
. Stop bits: 1
. Flow Control none
A typical console connection is illustrated below:
Figure 3-1: Console Setting Environment
3.3 Set Up your Switch Using Telnet Access
Once you have set an IP address for your Switch, you can use a Telnet program (in a
VT-100 compatible terminal mode) to access and control the Switch. Most of the screens are
identical, whether accessed from the console port or from a Telnet interface.
