LACP Mode - Selects the Link Aggregation Control Protocol administration state. The
mode must be enabled in order for the port to participate in Link Aggregation. May be
enabled or disabled by selecting the corresponding line on the pulldown entry field. The
factory default is enabled.
Physical Mode - Use the pulldown menu to select the port's speed and duplex mode. If
you select auto the duplex mode and speed will be set by the auto-negotiation process.
Note that the port's maximum capability (full duplex and 100 Mbps) will be advertised.
Otherwise, your selection will determine the port's duplex mode and transmission rate.
The factory default is auto. The selection when applied against the "All" option in Slot/Port
is applied to all applicable interfaces only.
Host Mode - Selects the dot1x protocol host type. Single-host means accept only one
user on this port. Multi-host means accept multi users on this port.
Link Trap - This object determines whether or not to send a trap when link status changes.
The factory default is enabled.
Maximum Frame Size - The maximum Ethernet frame size the interface supports or is
configured, including Ethernet header, CRC, and payload. (1518 to 9216). The default
maximum frame size is 1518 .
Flow Control - Used to enable or disable flow control feature on the selected interface.
Broadcast Storm Control - Used to enable or disable the broadcast storm feature on the
selected interface. The broadcast storm control value can be set to Level 1, Level 2, Level
3, and Level 4.
The following description is for the broadcast storm, multicast storm, and unicast
storm control.
The actual packet rate for switch will convert from the input level and the speed of that
interface. (see table 1 and table 2)
Table 1. For
10/100Mbps/1Gbps
Table 2. For 10Gbps
Level
1
64
1
1042
2
128
2
2048
3
256
3
3124
4
512
4
4167
Multicast Storm Control - Used to enable or disable the multicast storm feature on the
selected interface. Multicast storm control value could be set Level 1, Level 2, Level 3, and
Level 4.
Unicast Storm Control - Used to enable or disable unicast storm feature on the selected
interface. Unicast storm control value could be set Level 1, Level 2, Level 3, and Level 4.
Capability - You could advertise the port capabilities of a given interface during
