Maximum VLAN Entries - The maximum number of Virtual LANs (VLANs) allowed on this
switch.
Most VLAN Entries Ever Used - The largest number of VLANs that have been active on
this switch since the last reboot.
Static VLAN Entries - The number of presently active VLAN entries on this switch that
have been created statically.
Dynamic VLAN Entries - The number of presently active VLAN entries on this switch that
have been created by GVRP registration.
VLAN Deletes - The number of VLANs on this switch that have been created and then
deleted since the last reboot.
Time Since Counters Last Cleared - The elapsed time, in days, hours, minutes, and
seconds, since the statistics for this switch were last cleared.
Command Buttons
Clear Counters - Clear all the counters, resetting all switch summary and detailed
statistics to default values. The discarded packets count cannot be cleared.
Refresh - Refresh the data on the screen with the present state of the data in the switch.
