Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 730/970
11.2.2.12.3. IGMP Snooping Querier VLAN Configuration Summary Page
Configurable Data
VLAN ID Search- Enter VLAN ID, then click on the search button. If the record exists,
that entry will be displayed. An exact match is required.
Non-Configurable Data
Admin Mode - Display the administrative mode for IGMP Snooping for the switch.
VLAN ID Search- Enter VLAN ID, then click on the search button. If the record exists,
that entry will be displayed. An exact match is required.
Querier Election Participate Mode - Displays the querier election participate mode on
the VLAN. When this mode is disabled, up on seeing a query of the same version in the
vlan, the snooping querier move to non querier state. Only when this mode is enabled,
the snooping querier will participate in querier election where in the least ip address will
win the querier election and operates as the querier in that VLAN. The other querier
moves to non-querier state.
Snooping Querier VLAN Address - Displays the Snooping Querier Address to be used
as source address in periodic IGMP queries sent on the specified VLAN.
Command Buttons
Search - Search for the specified Vlan ID.
Refresh - Reload the information on the page.
