Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 753/970
11.2.2.17.4. Configuring each Port CST Configuration Page
Selection Criteria
Slot/Port - Selects one of the physical or LAG interfaces associated with VLANs
associated with the CST.
Configurable Data
Port Priority - The priority for a particular port within the CST. The port priority is set in
multiples of 16. For example, if you attempt to set the priority to any value between 0 and
15, it will be set to 0. If you attempt to set any value between 16 and (2*16-1) it will be set
to 16 and so on.
Admin Edge Port - Specifies if the specified port is an Edge Port within the CIST. It takes
a value of Enable or Disable, where the default value is Disable.
Port Path Cost - Set the Path Cost to a new value for the specified port in the common
and internal spanning tree. It takes a value in the range of 1 to 200000000.
External Port Path Cost - Set the External Path Cost to a new value for the specified port
in the spanning tree. It takes a value in the range of 1 to 200000000.
Port Mode - Spanning Tree Protocol Administrative Mode associated with the port or port
channel. The possible values are Enable or Disable.
Non-Configurable Data
Auto-calculate Port Path Cost - Displays whether the path cost is automatically
calculated (Enabled) or not (Disabled). Path cost will be calculated based on the link
