Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 766/970
Transmit Total - Specifies the number of LLDP frames transmitted by the LLDP agent on
the corresponding port.
Receive Total - Specifies the number of valid LLDP frames received by this LLDP agent
on the corresponding port, while the LLDP agent is enabled.
Discards - Specifies the number of LLDP TLVs discarded for any reason by the LLDP
agent on the corresponding port.
Errors - Specifies the number of invalid LLDP frames received by the LLDP agent on the
corresponding port, while the LLDP agent is enabled.
Age outs - Specifies the number of age-outs that occurred on a given port. An age-out is
the number of times the complete set of information advertised by a particular MAC
Service Access Point (MSAP) has been deleted from tables associated with the remote
entries because information timeliness interval had expired.
TLV Discards - Specifies the number of LLDP TLVs discarded for any reason by the LLDP
agent on the corresponding port.
TLV Unknowns - Specifies the number of LLDP TLVs received on the local ports which
were not recognized by the LLDP agent on the corresponding port.
Command Buttons
Refresh - Updates the information on the page.
Clear - Clears LLDP Statistics of all the interfaces.
11.2.2.20.5. Viewing LLDP Local Device Information Page
Selection Criteria
