Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 787/970
11.2.3.2.3. Configuring IP Interfaces
Selection Criteria
Slot/Port - Select the interface for which data is to be displayed or configured.
Configurable Data
IP Address - Enter the IP address for the interface.
Subnet Mask - Enter the subnet mask for the interface. This is also referred to as the
subnet/network mask, and defines the portion of the interface's IP address that is used to
identify the attached network.
Routing Mode - Setting this enables or disables routing for an interface. The default
value is enable.
Administrative Mode - The Administrative Mode of the interface. The default value is
enable.
Forward Net Directed Broadcasts - Select how network directed broadcast packets
should be handled. If you select enable from the pulldown menu network directed
broadcasts will be forwarded. If you select disable they will be dropped. The default value
is disable.
Encapsulation Type - Select the link layer encapsulation type for packets transmitted
from the specified interface from the pulldown menu. The possible values are Ethernet
and SNAP. The default is Ethernet.
Proxy Arp - Select to disable or enable proxy Arp for the specified interface from the
pulldown menu.
