11.2.6.1.5. IPv6 Access Control List Summary Page
Non-Configurable Data
IPv6 ACL Name - Exiting IPv6 ACL identifier.
Rules - The number of rules currently configured for the IPv6 ACL.
Direction - The direction of packet traffic affected by the IPv6 ACL.
Direction can only be one of the following:
Inbound
Slot/Port(s) - The interfaces to which the IPv6 ACL applies.
VLAN(s) - VLAN(s) to which the IPv6 ACL applies.
Command Buttons
Refresh - Refresh the data on the screen to the latest state.
11.2.6.1.6. IPv6 Access Control List Rule Configuration Page
Use these screens to configure the rules for the IPv6 Access Control Lists, which is created
using the IPv6 Access Control List Configuration screen. By default, no specific value is in
effect for any of the IPv6 ACL rules.
Selection Criteria
IPv6 ACL Name - Use the pull down menu to select the IPv6 ACL for which to create or
update a rule.
