Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 947/970
Number of Groups - The current number of entries for the selected interface in the cache
table.
Command Buttons
Refresh - Refresh the data on the screen with the present state of the data in the router.
11.2.7.2.4. Viewing IGMP Cache Information Page
Selection Criteria
Slot/Port - Select the Slot and port for which data is to be displayed. Slot 0 is the base unit.
Multicast Group IP - Select the IP multicast group address for which data is to be
displayed. If no group membership reports have been received on the selected interface
you will not be able to make this selection, and none of the non-configurable data will be
displayed.
Non-Configurable Data
