8400 HighLine | Parameter setting & configuration
I/O terminals
Digital input terminals
224 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
Internal interfaces to the application
 Relevant outputs at LS_DigitalInput
system block:
Related topics:
Using DI1(6) and DI2(7) as digital inputs
( 220)
Using DI1(6) as counting input
( 225)
Internal interfaces | System block "LS_DigitalInput"
( 229)
Output
Data type
Value/meaning
Frequency input DI1/DI2
nFreqIn12_a
C00446/1 | INT
Output frequency as scaled analog signal in [%]
nFreqIn12_v
C00445/1 | INT
Output frequency as speed signal in [inc/ms]
Frequency input DI6/DI7
nFreqIn67_a
C00446/2 | INT
Output frequency as scaled analog signal in [%]
nFreqIn67_v
C00445/2 | INT
Output frequency as speed signal in [inc/ms]
