8400 HighLine | Parameter setting & configuration
I/O terminals
Analog terminals
236 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
Related topics:
Configuring exception handling of the output terminals
( 244)
User-defined terminal assignment
( 245)
Electrical data
( 252)
Analog output 1
C00439/1 O1U: Input value (from application) - %
C00439/3 O1I: Input value (from application) - %
C00436/1 O1U: Voltage - V
C00437/1 O1I: Current - mA
Analog output 2
C00439/2 O2U: Input value (from application) - %
C00439/4 O2I: Input value (from application) - %
C00436/2 O2U: Voltage - V
C00437/2 O2I: Current - mA
Analog outputs - terminal assignment
C00620/1
LS_AnalogOutput: nOut1_a (V) 1003: LA_nCtrl_nMotorSpeedAct_a
C00620/39
LS_AnalogOutput: nOut1_a (I) 0: Not connected
C00620/38
LS_AnalogOutput: nOut2_a (V) 0: Not connected
C00620/40
LS_AnalogOutput: nOut2_a (I) 0: Not connected
Parameter Info Lenze setting
Value Unit
Highlighted in grey = display parameter
