Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010 L 255
8400 HighLine | Parameter setting & configuration
I/O terminals
Electrical data
*) In order to filter short-time interference in the analog signal characteristic, four measurements of the analog input value are carried out within the
conversion rate (1 kHz = 1 ms) after which the mean value is determined. The mean value corresponds to the process signal at the output of the system
block. In addition, the voltage input has a low-pass filter (3 dB-limit frequency, f = 470 Hz for voltage input, f = 250 Hz for current input)
X3/O1U
X3/O2U
Voltage output Level: 0 ... +10 V
(max. 2 mA)
Resolution: 10 bits
(Error: 1 digit ≡ 0.1 %, in relation to the final
value)
Scaling: ±10 V ≡ ±2
14
≡ 16384 ≡ ±100 %
Processing cycle 1 kHz (1 ms)
Limit frequency 315 Hz at -3 dB
Temperature influence ± 0.5 % or ± 1 mV/K
(T
amb
= - 10° C ... + 55° C)
X3/O1I
X3/O2I
Current output Level: 0 ... +20 mA
Resolution: 10 bits
(Error: 1 digit ≡ 0.1 %, in relation to the final
value)
Scaling: ±20 mA ≡ ±2
14
≡ 16384 ≡ ±100 %
Processing cycle 1 kHz (1 ms)
Temperature influence ± 0.5 % or ± 1 mV/K
(T
amb
= - 10° C ... + 55° C)
Terminal Use Electrical data
