8400 HighLine | Parameter setting & configuration
I/O terminals
Electrical data
254 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
Analog terminals
Terminal Use Electrical data
X3/A1U
X3/A2U
Voltage input Level: - 10 V ... + 10 V
Resolution: 10 bit + sign bit
(Error: 1 digit ≡ 0.1 %, in relation to the final
value)
Scaling: When C00034
="0":
±10 V ≡ ±2
14
≡ 16384 ≡ ± 100 %
Conversion rate: 1 kHz
*)
Input resistance > 80 kΩ
Input voltage in case of open
circuit
Display 0 (U < 0.2 V, abs.)
Sampling frequency
(processing cycle)
1 kHz (1 ms)
Accuracy ± 0.1 V
Electric strength of external
voltage
± 15 V, permanent
Limit frequency 315 Hz at -3 dB
Temperature influence ± 0.5 % or ± 1 mV/K
(T
amb
= - 10° C ... + 55° C)
X3/A1I
X3/A2I
Current input Level: • 0 ... + 20 mA
• + 4 ... + 20 mA (life zero)
Resolution: 10 bits
(Error: 1 digit ≡ 0.1 %, in relation to the final
value)
Switching hysteresis: 1 % (at 20 mA)
Scaling: When C00034
="1":
0 mA ... + 20 mA = 0 ... + 2
14
When C00034 ="2":
+ 4 mA ... + 20 mA = 0 ... + 2
14
Conversion rate: 1 kHz
*)
Input resistance 215 Ω
Input voltage in case of open
circuit
Display 0 (I < 0.1 mA)
Sampling frequency
(processing cycle)
1 kHz (1 ms)
Accuracy ± 0.1 mA
Electric strength of external
voltage
± 7 V, permanent
Temperature influence ± 0.5 % or ± 1 mV/K,
(T
amb
= - 10° C ... + 55° C)
X3/GA GND, reference potential of analog signals
X3
A1U
AR
A1I
A2U
A2IGA
O1U
O1I
O2UO2I
