8400 HighLine | Parameter setting & configuration
Technology applications
TA "Table positioning"
300 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
dnPosProfilePosition_p
DINT
Selection of the target position in [increments]
• The mode for calculating the position is selected in C01296/1
.
wPosProfileUnitsLW
wPosProfileUnitsHW
WORD
Selection of the target position in [units]
• wPosProfileUnitsLW = Low word, wPosProfileUnitsHW = High word
• The mode for calculating the position is selected in C01296/1
.
GP: GeneralPurpose
The following inputs are interconnected with logic/arithmetic functions on application level for free usage.
"GeneralPurpose" functions
nGPAnalogSwitchIn1_a
nGPAnalogSwitchIn2_a
INT
Analog switch: Input signals
• The input signal selected via the selection input bGPAnalogSwitchSet is output at
output nGPAnalogSwitchOut_a.
bGPAnalogSwitchSet
BOOL
Analog switch: Selection input
FALSE nGPAnalogSwitchOut_a = nGPAnalogSwitchIn1_a
TRUE nGPAnalogSwitchOut_a = nGPAnalogSwitchIn2_a
nGPArithmetikIn1_a
nGPArithmetikIn2_a
INT
Arithmetic: Input signals
• The arithmetic function is selected in C00338
.
• The result is output at output nGPArithmetikOut_a.
nGPMulDivIn_a
INT
Multiplication/Division: Input signal
• The factor for the multiplication can be set in C00699/1
(numerator) and
C00699/2
(denominator).
• The result is output at output nGPMulDivOut_a.
bGPDigitalDelayIn
BOOL
Binary delay element: Input signal
• The on-delay can be set in C00720/1
.
• The off-delay can be set in C00720/2
.
• The time-delayed input signal is output at output bGPDigitalDelayOut.
bGPLogicIn1
bGPLogicIn2
bGPLogicIn3
BOOL
Binary logic: Input signals
• The logic operation is selected in C00820
.
• The result is output at output bGPLogicOut.
nGPCompareIn1_a
nGPCompareIn2_a
INT
Analog comparison: Input signals
• The comparison operation is selected in C00680
.
• Hysteresis and window size can be set in C00680
and C00682.
• If the comparison statement is true, the output bGPCompareOut will be set to
TRUE.
bGPDFlipFlop_InD
bGPDFlipFlop_InClk
bGPDFlipFlop_InClr
BOOL
D-FlipFlop: Input signals
• Data, clock and reset input
bGPCounter1ClkUp
BOOL
Counter: Clock input
• With each edge, the module counts up by "1".
• Only FALSE-TRUE edges are evaluated.
Note: The static state "1" is not permissible at this input.
bGPCounter1ClkDown
BOOL
Counter: Clock input
• With each edge, the module counts down by "1".
• Only FALSE-TRUE edges are evaluated.
Note: The static state "1" is not permissible at this input.
bGPCounter1Load
BOOL
Counter: Loading input
• The input has the highest priority.
TRUE Accept the starting value wGPCounter1LdVal.
wGPCounter1LdVal
WORD
Counter: Starting value
• Assigned value is internally interpreted as "INT" data type (-32767 ... +32767), i.e.
the most significant bit determines the sign.
wGPCounter1CmpVal
WORD
Counter: Comparison value
• Assigned value is internally interpreted as "INT" data type (-32767 ... +32767), i.e.
the most significant bit determines the sign.
Identifier
Data type
Information/possible settings
