Lenze E84AVHC Series User Manual

8400 HighLine | Parameter setting & configuration
Technology applications
TA "Table positioning"
320 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
wOut2 LA_TabPos.nGPSignalOut1_a Analog signal monitor: Output signal 1
• The selection of the signal source to output is executed in
C00410/1
.
• Gain and offset for the output signal can be
parameterised in C00413/1
and C00413/2.
• For a detailed functional description see
FB L_SignalMonitor_a
.
wOut3 - -
wOut4 - -
wOut5 LA_TabPos.nMotorSpeedAct_a Actual speed value
• Scaling: 16384 ≡ 100 % rated speed (C00011
)
wOut6 - -
...
wOut16
dnOut34_p LA_TabPos.dnSetPos_p Absolute position setpoint in [increments]
• 65535 [Increments] ≡ 1 motor revolution
• The position resolution, i.e. how many increments form
one unit, is displayed in C01205
.
