8400 HighLine | Parameter setting & configuration
Device control (DCTRL)
Internal interfaces | "LS_DriveInterface" system block
92 L Firmware ≤ 05.00 - DMS 4.2 EN - 02/2010
Inputs
Identifier
DIS code | data type
Information/possible settings
wCANControl
C00136/2 | WORD
Control word via system bus (CAN)
• The controller controlled by a master control (e.g. IPC) receives its control word by
the CANopen system bus interface. The process data word is provided at this
input by the upstream port block LP_CanIn1
.
• See the "wCANControl/wMCIControl control words
" chapter for a detailed
description of the individual control bits. ( 94)
wMCIControl
C00136/1 | WORD
Control word via communication module (e.g. PROFIBUS)
• The controller controlled by a master control (e.g. IPC) receives its control word by
a plugged-in communication module. The process data word is provided at this
input by the upstream port block LP_MciIn1
.
• See the "wCANControl/wMCIControl control words
" chapter for a detailed
description of the individual control bits. ( 94)
bCInh
C00833/36 | BOOL
Enable/Inhibit controller ( 72)
FALSE Enable controller: The controller switches to the "OperationEnabled
"
device state, if no other source of a controller inhibit is active.
• C00158
provides a bit coded representation of all active sources/
triggers of a controller inhibit.
TRUE Inhibit controller (controller inhibit): The controller switches to the
"SwitchedON
" device state.
bFailReset
C00833/37 | BOOL
Reset of error message ( 474)
TRUE The current error is reset.
bStatus_Bit0
bStatus_Bit2
bStatus_Bit3
bStatus_Bit4
bStatus_Bit5
bStatus_Bit14
bStatus_Bit15
C00833/38 ... 44 | BOOL
Freely assignable bits in the status word of the controller.
• You can use these bits for returning information to the master control (e.g. IPC).
