Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 734/970
a report for a particular group on a particular interface before it deletes that interface from
the group. The valid range is from (2 to 3600) seconds. The configured value must be
greater than Max Response Time. The default is 260 seconds.
Max Response Time - Specify the amount of time you want the switch to wait after
sending a query on an interface because it did not receive a report for a particular group
on that interface. Enter a value greater or equal to 1 and less than the Group Membership
Interval in seconds. The default is 10 seconds. The configured value must be less than
the Group Membership Interval.
Multicast Router Present Expiration Time - Specify the amount of time you want the
switch to wait to receive a query on an interface before removing it from the list of
interfaces with multicast routers attached. Enter a value between 0 and 3600 seconds.
The default is 0 seconds. A value of zero indicates an infinite timeout, i.e. no expiration.
Fast Leave Admin mode - Select the Fast Leave mode for the a particular interface from
the pulldown menu. The default is disable.
Command Buttons
Submit - Update the switch with the values you entered. If you want the switch to retain
the new values across a power cycle you must perform a save. You will only see this
button if you have Read/Write access privileges.
11.2.2.13.3. Configuring MLD Snooping VLAN Status Page
Non-Configurable Data
VLAN ID - All Vlan Ids for which the MLD Snooping mode is Enabled.
Admin Mode - MLD Snooping Mode for Vlan ID.
Fast Leave Admin Mode - Fast Leave Mode for Vlan ID.
