UANTA COMPUTER INC.
Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 735/970
Group Membership Interval - Group Membership Interval of MLD Snooping for the
specified VLAN ID. Valid range is 2 to 3600.
Maximum Response Time - Maximum Response Time of MLD Snooping for the
specified VLAN ID. Valid range is 1 to 3599.Its value should be greater than group
membership interval value.
Multicast Router Expiry Time - Multicast Router Expiry Time of MLD Snooping for the
specified VLAN ID. Valid range is 0 to 3600.
Command Buttons
Refresh - Re-fetch the database and display it again starting with the first entry in the
table.
11.2.2.13.4. Configuring MLD Snooping VLAN Configuration Page
Configurable Data
VLAN ID - Specifies list of VLAN IDs for which MLD Snooping is enabled.
VLAN ID - Appears when "New Entry" is selected in VLAN ID combo box. Specifies VLAN
ID for which pre-configurable Snooping parameters are to be set.
Fast Leave Admin Mode - Enable or disable the MLD Snooping Fast Leave Mode for the
specified VLAN ID.
Group Membership Interval - Sets the value for group membership interval of MLD
Snooping for the specified VLAN ID. Valid range is (Maximum Response Time + 1) to
3600.
Maximum Response Time - Sets the value for maximum response time of MLD
Snooping for the specified VLAN ID. Valid range is 1 to (Group Membership Interval -
1).Its value should be less than group membership interval value.
Multicast Router Expiry Time - Sets the value for multicast router expiry time of MLD
Snooping for the specified VLAN ID. Valid range is 0 to 3600.
None-Configurable Data
Admin Mode - Enable MLD Snooping for the specified VLAN ID.
