UANTA COMPUTER INC.
Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 736/970
Command Buttons
Submit - Update the switch with the values you entered.
Delete - Update the switch with the default values.
11.2.2.13.5. Configuring Multicast Router Status Page
Non-Configurable Data
Slot/Port - The single select box lists all physical and LAG interfaces. Select the interface
for which you want to display the status.
Multicast Router - Specifies for the selected interface whether multicast router is enable
or disabled.
Command Buttons
Refresh - Re-fetch the database and display it again starting with the first entry in the
table.
11.2.2.13.6. Configuring Multicast Router Status Page
Configurable Data
Slot/Port - The select box lists all Slot/Ports. Select the interface for which you want
