Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 773/970
11.2.2.21.4. Configuring LLDP-MED Local Device Information Page
Selection Criteria
Interface - Specifies the list of all the ports on which LLDP-MED frames can be
transmitted.
Non-Configurable Data
Network Policy Information - Specifies if network policy TLV is present in the LLDP
frames.
Media Application Type
- Specifies the application type. Types of application types
are unknown, voicesignaling, guestvoice, guestvoicesignalling, softphonevoice,
videoconferencing, streammingvideo, vidoesignalling. Each application type that is
received has the VLAN id, priority, DSCP, tagged bit status and unknown bit status. A
port may receive one or many such application types. If a network policy TLV has
been transmitted only then would this information be displayed.
Vlan Id - Specifies the VLAN id associated with a particular policy type.
Priority - Specifies the priority associated with a particular policy type.
DSCP - Specifies the DSCP associated with a particular policy type.
Unknown Bit Status
- Specifies the unknown bit associated with a particular policy
type.
