Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 775/970
11.2.2.21.5. Configuring LLDP-MED Remote Device Information Page
Selection Criteria
Local Interface - Specifies the list of all the ports on which LLDP-MED is enabled.
Non-Configurable Data
Capability Information - Specifies the supported and enabled capabilities that was
received in MED TLV on this port.
Supported Capabilities
- Specifies supported capabilities that was received in MED
TLV on this port.
Enabled Capabilities - Specifies enabled capabilities that was received in MED TLV
on this port.
Device Class - Specifies device class as advertised by the device remotely
connected to the port.
Network Policy Information - Specifies if network policy TLV is received in the LLDP
frames on this port.
Media Application Type - Specifies the application type. Types of application types
are unknown, voicesignaling, guestvoice, guestvoicesignalling, softphonevoice,
videoconferencing, streammingvideo, vidoesignalling. Each application type that is
received has the VLAN id, priority, DSCP, tagged bit status and unknown bit status. A
port may receive one or many such application types. If a network policy TLV has
been receive on this port only then would this information be displayed.
VLAN Id - Specifies the VLAN id associated with a particular policy type.
Priority - Specifies the priority associated with a particular policy type.
