Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 791/970
11.2.3.3.2. Configuring Area
Selection Criteria
Area ID - Select the area to be configured.
Configurable Data
Import Summary LSAs - Select enable or disable from the pulldown menu. If you select
enable summary LSAs will be imported into stub areas.
Metric Value - Enter the metric value you want applied for the default route advertised
into the stub area. Valid values range from 1 to 16,777,215.
Metric Type - Select the type of metric specified in the Metric Value field.
OSPF Metric - Regular OSPF metric
Comparable Cost - External Type 1 metrics that are comparable to the OSPF metric
Non-comparable Cost - External Type 2 metrics that are assumed to be larger than
the cost of the OSPF metric
