Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 794/970
11.2.3.3.4. Configuring Area Range
Selection Criteria
Area ID - Selects the area for which data is to be configured.
Configurable Data
IP address - Enter the IP Address for the address range for the selected area.
Subnet Mask - Enter the Subnet Mask for the address range for the selected area.
LSDB Type - Select the type of Link Advertisement associated with the specified area
and address range. The default type is 'Network Summary'.
Advertisement - Select enable or disable from the pulldown menu. If you selected
enable the address range will be advertised outside the area via a Network Summary
LSA. The default is enable.
Non-Configurable Data
Area ID - The OSPF area.
IP address - The IP Address of an address range for the area.
Subnet Mask - The Subnet Mask of an address range for the area.
LSDB Type - The Link Advertisement type for the address range and area.
Advertisement - The Advertisement mode for the address range and area.
Command Buttons
Create - Send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is
performed. The new address range will be added to the display in the non-configurable
data area.
Delete - Removes the specified address range from the area configuration.
