Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 807/970
11.2.3.3.12. Configuring OSPF Route Redistribution
This screen can be used to configure the OSPF Route Redistribution parameters. The
allowable values for each fields are displayed next to the field. If any invalid values are entered,
an alert message will be displayed with the list of all the valid values.
Configurable Data
Configured Source - This select box is a dynamic selector and would be populated by
only those Source Routes that have already been configured for redistribute by OSPF.
However, the topmost option in the select box would be "Create", and this allows the user
to configure another, among the Available Source Routes. The valid values are 'Static',
'Connected', 'RIP' ,'BGP' and 'Create'.
Available Source - This select box is a dynamic selector and would be populated by only
those Source Routes that have not previously been configured for redistribution by OSPF.
This select box would appear only if the user selects "Create" option as Configured
Source. The valid values are 'Static', 'Connected', 'RIP' and 'BGP'.
Metric- Sets the metric value to be used as the metric of redistributed routes. This field
displays the metric if the source was pre-configured and can be modified. The valid
values are (0 to 16777215)
Metric Type - Sets the OSPF metric type of redistributed routes.
Tag - Sets the tag field in routes redistributed. This field displays the tag if the source was
pre-configured, otherwise 0 and can be modified. The valid values are 0 to 4294967295.
Subnets - Sets whether the subnetted routes should be redistributed or not.
Distribute List - Sets the Access List that filters the routes to be redistributed by the
destination protocol. Only permitted routes are redistributed. If this command refers to a
non-existent access list, all routes are permitted. The valid values for Access List IDs are
(1 to 199). When used for route filtering, the only fields in an access list that get used are

Source IP Address and netmask

Destination IP Address and netmask

Action (permit or deny)
