Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 833/970
Virtual IP Address - The IP Address associated with the Virtual Router.
Interface IP Address - The actual IP Address associated with the interface used by the
Virtual Router.
Owner - Set to 'True' if the Virtual IP Address and the Interface IP Address are the same,
otherwise set to 'False'. If this parameter is set to 'True', the Virtual Router is the owner of
the Virtual IP Address, and will always win an election for master router when it is active.
VMAC Address - The virtual MAC Address associated with the Virtual Router, composed
of a 24 bit organizationally unique identifier, the 16 bit constant identifying the VRRP
address block and the 8 bit VRID.
Auth Type - The type of authentication in use for the Virtual Router

None

Simple
State - The current state of the Virtual Router:

Initialize

Master

Backup
Status - The current status of the Virtual Router:

Inactive

Active
Secondary IP Address - The secondary IP address.
Command Buttons
Refresh - Refresh the data on the screen with the present state of the data in the switch.
11.2.3.10.4. Viewing Virtual Router Statistics
Selection Criteria
