Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 845/970
11.2.4.1.4. Viewing Access Control Summary Page
Non-Configurable Data
Port - Specifies the port whose settings are displayed in the current table row.
Control Mode - This field indicates the configured control mode for the port. Possible
values are:
Force Unauthorized: The authenticator port access entity (PAE) unconditionally sets
the controlled port to unauthorized.
Force Authorized: The authenticator PAE unconditionally sets the controlled port to
authorized.
Auto: The authenticator PAE sets the controlled port mode to reflect the outcome of
the authentication exchanges between the supplicant, authenticator, and the
authentication server.
Operating Control Mode - This field indicates the control mode under which the port is
actually operating. Possible values are:
ForceUnauthorized
ForceAuthorized
Auto
Reauthentication Enabled - This field shows whether reauthentication of the supplicant
for the specified port is allowed. The possible values are 'true' and 'false'. If the value is
