Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 882/970
Area ID - Select the area to be configured.
Configurable Data
Import Summary LSAs - Select enable or disable from the pulldown menu. If you select
enable summary LSAs will be imported into areas. Defaults to Enable.
Stub Area Specific Parameters.
Metric Value - Enter the metric value you want applied for the default route advertised into
the stub area. Valid values range from 1 to 16,777,215. This value is applicable only to
Stub areas.
NSSA Specific Parameters.
Default Information Originate - The default Route Information. This can also be applied
by the CLI command 'area (area-id) nssa default-info-originate' in the ipv6 router ospf
config mode. Valid values are True or False.
Default Metric - Set the Default Metric value for NSSA. The valid range of values is (1 to
16777214).
Metric Type Type - Select the type of metric specified in the Metric Value field.
•
Default - The default metric value. On CLI this value shows up as "-------"
•
Comparable Cost - External Type 1 metrics that are comparable to the OSPFv3
metric
•
Non-comparable Cost - External Type 2 metrics that are assumed to be larger
than the cost of the OSPFv3 metric
Translator Role - NSSA Border router's ability to perform NSSA translation of type-7 LSAs
into type-5 LSAs. The valid values are 'Always' and 'Candidate'.
Translator Stability Interval - The number of seconds after an elected translator
determines its services are no longer required, that it should continue to perform its
translation duties. The valid range of values is (0 to 3600).
No-Redistribute Mode - Enable or Disable the No-Redistribute Mode.
Non-Configurable Data
Area ID - The OSPFv3 area. An Area ID is a 32 bit integer in dotted decimal format that
uniquely identifies the area to which a router interface connects.
External Routing - A definition of the router's capabilities for the area, including whether
or not AS-external-LSAs are flooded into/throughout the area.
SPF Runs - The number of times that the intra-area route table has been calculated using
this area's link-state database. This is done using Dijkstra's algorithm.
