Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 883/970
Area Border Router Count - The total number of area border routers reachable within
this area. This is initially zero, and is calculated in each SPF Pass.
Area LSA Count - The total number of link-state advertisements in this area's link-state
database, excluding AS External LSAs.
Area LSA Checksum - The 32-bit unsigned sum of the link-state advertisements' LS
checksums contained in this area's link-state database. This sum excludes external (LS
type 5) link-state advertisements. The sum can be used to determine if there has been a
change in a router's link state database, and to compare the link-state database of two
routers.
Stub Area Specific Parameters.
Metric Value - The Configured Metric value for the Stub. This can be modified using the
CLI command 'area (area-id) default-cost' in the ipv6 router ospf config mode. The valid
range is (1 to 16777215).
NSSA Specific Parameters.
Translator State - Translator State 'Enabled' means that the NSSA router OSPFv3 Area
NssA Translator Role has been set to always. Translator State of 'Elected' means a
candidate NSSA Border router is translating type-7 LSAs into type-5.' Disabled' implies tha
a candidate NSSA Border router is NOT translating type-7 LSAs into type-5.
Command Buttons
Create Stub Area - Configure the area as a stub area.
Delete Stub Area - Delete the stub area designation. The area will be returned to normal
state.
Create NSSA - Configure the area as NSSA.
Delete NSSA - Delete the NSSA designation. The area will be returned to normal state.
Submit - Send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is
performed.
