11.2.6.1.7. Configuring MAC Access Control List Configuration Page
A MAC ACL consists of a set of rules which are matched sequentially against a packet. When a
packet meets the match criteria of a rule, the specified rule action (Permit/Deny) is taken and
the additional rules are not checked for a match. On this menu the interfaces to which an MAC
ACL applies must be specified, as well as whether it applies to inbound or outbound traffic.
Rules for the MAC ACL are specified/created using the MAC ACL Rule Configuration menu.
Selection Criteria
MAC ACL - A new MAC Access Control List may be created or the configuration of an
existing MAC ACL can be updated based on selection.
Configurable Data
MAC ACL Name - Specifies MAC ACL Name string which may include alphabetic,
numeric, dash, underscore or space characters only. The name must start with an
alphabetic character. This field displays the name of the currently selected MAC ACL if
the ACL has already been created.
Command Buttons
Submit - Send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is
performed.
