Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 929/970
11.2.6.2.9. Viewing DiffServ Service Summary Page
Non-Configurable Data
Slot/Port - Shows the Slot/Port that uniquely specifies an interface.
Direction - Shows the traffic direction of this service interface, either In or Out.
Operational Status - Shows the operational status of this service interface.
Policy Name - Shows the name of the attached policy.
11.2.6.2.10. Viewing DiffServ Service Statistics Page
This screen displays service-level statistical information in tabular form for all interfaces in the
system to which a DiffServ policy has been attached in the inbound and/or outbound traffic
directions. Use the 'Counter Mode Selector' to specify the counter display mode as either
octets or packets (the default).
Non-Configurable Data
Slot/Port - Shows the Slot/Port that uniquely specifies an interface.
Direction - Shows the traffic direction of this service interface.
Operational Status - Shows the operational status of this service interface, either Up or
Down.
11.2.6.2.11. Viewing DiffServ Service Detailed Statistics Page
This screen displays class-oriented statistical information for the policy, which is specified by
the interface and direction. The 'Member Classes' drop down list is populated on the basis of
the specified interface and direction and hence the attached policy (if any). Highlighting a
member class name displays the statistical information for the policy-class instance for the
