Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 936/970
Configurable Data
Minimum Bandwidth Allocated - Specifies the sum of individual Minimum Bandwidth
values for all queues in the interface. The sum cannot exceed the defined maximum
(100). This value is considered while configuring the Minimum Bandwidth for a queue in
the selected interface.
Command Buttons
Restore Defaults for All Queues - Restores default settings for all queues on the
selected interface.
Submit - Send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is
performed.
11.2.6.4.5. Viewing CoS interface queue status
Selection Criteria
Slot/Port - Specifies all CoS configurable interfaces. The option "Global" represents the
most recent global configuration settings. These may be overridden on a per-interface
basis.
Non-Configurable Data
Queue ID - Specifies the queueID.
Minimum Bandwidth - Specifies the minimum guaranteed bandwidth allotted to this
queue. The value 0 means no guaranteed minimum. Sum of individual Minimum
Bandwidth values for all queues in the selected interface cannot exceed defined
maximum (100).
