Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 939/970
11.2.7.1.3. Viewing DVMRP Configuration Summary
Selection Criteria
o
Slot/Port - Select the interface for which data is to be displayed. You must configure at
least one router interface before you can display data for a DVMRP interface. Otherwise
you will see a message telling you that no router interfaces are available, and the
configuration summary screen will not be displayed.
Non-Configurable Data
Interface Mode - The administrative mode of the selected DVMRP routing interface, either
enable or disable.
Protocol State - The operational state of the DVMRP protocol on the selected interface,
either operational or non-operational.
Local Address - The IP address used as a source address in packets sent from the
selected interface.
Interface Metric - The metric used to calculate distance vectors for the selected interface.
Generation ID - The DVMRP generation ID used by the router for the selected interface.
This value is reset every time an interface is (re)started and is placed in prune messages. A
change in generation ID informs the neighbor routers that any previous information about
this router should be discarded.
Received Bad Packets - The number of invalid packets received on the selected interface.
Received Bad Routes - The number of invalid routes received on the selected interface.
Sent Routes - The number of routes sent on the selected interface.
Neighbor IP - The IP address of the neighbor whose information is displayed.
