Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 965/970
Join/Prune Interval - Enter the interval between the transmission of PIM-SM Join/Prune
messages. The valid values are from (10 to 3600 secs). The default value is 60.
Data Threshold Rate - Enter the minimum source data rate in K bits/second above which
the last-hop router will switch to a source-specific shortest path tree. The valid values are
from (0 to 2000 K bits/sec) . The default value is 50.
Register Threshold Rate - Enter the minimum source data rate in K bits/second above
which the Rendezvous Point router will switch to a source-specific shortest path tree. The
valid values are from (0 to 2000 K bits/sec) . The default value is 50.
Command Buttons
Submit - Send the updated configuration to the router. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is
performed.
11.2.7.6.2. Viewing PIM-SM Global Configuration Page
Non-Configurable Data
Admin Mode - The administrative status of PIM-SM in the router: either enable or disable.
Join/Prune Interval - The interval between the transmission of PIM-SM Join/Prune
messages.
Data Threshold Rate - The minimum source data rate in K bits/second above which the
last-hop router will switch to a source-specific shortest path tree.
Register Threshold Rate - The minimum source data rate in K bits/second above which
the Rendezvous Point router will switch to a source-specific shortest path tree.
Command Buttons
Refresh - Refresh the data on the screen with the present state of the data in the router.
