Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 966/970
11.2.7.6.3. Configuring Interface’s PIM-SM Configuration Page
Selection Criteria
Slot/Port - Select the slot and port for which data is to be displayed or configured. Slot 0 is
the base unit.
Configurable Data
Mode - Select enable or disable from the pulldown menu to set the administrative status of
PIM-SM in the router. The default is disable.
Hello Interval (secs)- Enter the time in seconds between the transmission of which PIM
Hello messages on this interface. The valid values are from (10 to 3600 secs) . The default
value is 30.
CBSR Preference - Enter the preference value for the local interface as a candidate
bootstrap router. The value of -1 is used to indicate that the local interface is not a
candidate BSR interface. The valid values are from (-1 to 255) The default value is 0.
CBSR Hash Mask Length - Enter the CBSR hash mask length to be advertised in
bootstrap messages if this interface is elected as the bootstrap router. This hash mask
length will be used in the hash algorithm for selecting the RP for a particular group. The
valid values are from (0 to 32). The default value is 30.
CRP Preference - Enter the preference value for the local interface as a candidate
bootstrap router. The value of -1 is used to indicate that the local interface is not a
candidate BSR interface. The valid values are from (-1 to 255). The default value is 0.
Command Buttons
Submit - Send the updated configuration to the router. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is
performed.
