Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 919/970
selected "MAC ACL" as "ACL Type".
Sequence Number - An optional sequence number may be specified to indicate the
order of this access list relative to other access lists already assigned to this interface and
direction. A lower number indicates higher precedence order. If a sequence number is
already in use for this interface and direction, the specified access list replaces the
currently attached access list using that sequence number. If the sequence number is not
specified by the user, a sequence number that is one greater than the highest sequence
number currently in use for this interface and direction will be used. Valid range is (1 to
4294967295).
Non-Configurable Data
Slot/Port - Displays selected interface.
Direction - Displays selected packet filtering direction for ACL.
ACL Type - Displays the type of ACL assigned to selected interface and direction.
ACL Identifier - Displays the ACL Number(in case of IP ACL) or ACL Name(in case of
MAC ACL) identifying the ACL assigned to selected interface and direction.
Sequence Number - Displays the Sequence Number signifying the order of specified
ACL relative to other ACLs assigned to selected interface and direction.
Command Buttons
Submit - Send the updated configuration to the switch. Configuration changes take effect
immediately. These changes will not be retained across a power cycle unless a save is
performed.
11.2.6.1.11. Configuring Access Control List VLAN ACL Configuration Page
Configurable Data
