Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 926/970
Member Class List - Displays all the member classes for the selected DiffServ policy. It is
automatically updated as a new class is added to or removed from the policy. Only when
an existing policy class instance is to be removed, is this field a selector field. After
removal of the policy class instance this becomes a non-configurable field.
Available Class List - Displays all the member classes for the specified policy. It is
automatically updated as a new class is added to or removed from the policy. Only when a
new policy class instance is to be created is this field a selector field. After creation of the
policy class instance this becomes a non-configurable field.
Command Buttons
Submit - Send the updated screen to the switch and cause the changes to take effect on
the switch but these changes will not be retained across a power cycle unless a save is
performed.
Delete - Delete the currently selected filter.
Rename - Allows to rename a specified policy.
Add Selected Class - Creates a policy class instance by attaching the policy to the
specified class.
Remove Selected Class - Removes a policy class instance by detaching the policy from
the specified class.
11.2.6.2.5. Viewing DiffServ Policy Summary Page
Non-Configurable Data
Policy Name - Displays name of the DiffServ policy.
