Layer 2,3,IPv6+QoS Switch
_____________________________________________________________________________
Layer 2,3,IPv6+QoS Network Switch User Manual Version 0.1 Page: 951/970
Version 2 Querier Timeout - The older IGMP version 2 querier timeout value in seconds.
Proxy Start Frequency - The number of times the proxy was brought up.
Proxy Interface Statistics - The Queries Received, Reports Received/Sent, Leaves
Received/Sent are displayed in the form a table for each IGMP version.
Command Buttons
Refresh - Refresh the data on the screen with the present state of the data in the router.
Clear Statistics - Clear the IGMP Proxy interface statistics.
11.2.7.2.8. Viewing IGMP Proxy Interface Membership Information Page
Selection Criteria
Multicast Group IP - Select the IP multicast group address for which data is to be
displayed. If no group membership reports have been received on the selected interface
you will not be able to make this selection, and none of the non-configurable data will be
displayed.
Non-Configurable Data
Slot/Port - Displays the interface on which IGMP proxy is enabled.
Last Reporter - The IP address of the source of the last membership report received for
the IP Multicast group address on the IGMP Proxy interface.
Uptime - The time elapsed since this entry was created.
State - The state of the host entry. A Host can be in one of the state. Non-member state -
does not belong to the group on the interface. Delaying member state - host belongs to the
group on the interface and report timer running. The report timer is used to send out the
reports. Idle member state - host belongs to the group on the interface and no report timer
running.
Number of Sources - The number of source hosts present in the selected multicast
group.
Command Buttons
