Enhanced Serial Communication Interface (eSCI)
MPC5566 Microcontroller Reference Manual, Rev. 2
21-16 Freescale Semiconductor
21.3.3.7 LIN Receive Register (ESCIx_LRR)
ESCIx_LRR can be ready only when ESCIx_SR[RXRDY] is set.
NOTE
Application software must ensure that ESCIx_LRR be read before new data
or checksum bytes or CRCs are received from the LIN bus.
4–7
Tn
Timeout bit n. Sets the counter to determine a NO_RESPONSE_ERROR, if the frame is a read access to a LIN
slave. Following LIN standard rev 1.3, the value (10 × N
DATA
+ 45) × 1.4 is recommended. For transmissions, this
counter has to be set to 0. The timeout bits 7–0 are not written on a TX frame. For TX frames, the fourth byte written
to the LIN transmit register (ESCIx_LTR) is the first data byte, for RX frames it contains timeout bits 7–0.The time is
specified in multiples of bit times. The timeout period starts with the transmission of the LIN break character.
8–31 Reserved.
Table 21-11. ESCIx_LTR Rx Frame Fourth Byte Field Description
Field Description
0–7
Tn
Timeout bit n. Sets the counter to determine a NO_RESPONSE_ERROR, if the frame is a read access to a LIN
slave. Follow the LIN standard rev 1.3, the value (10 × N
DATA
+45)× 1.4. For transmissions, this counter must be set
to 0. The timeout bits 7–0 are not written on a TX frame. For TX frames, the fourth byte written to the LIN transmit
register (ESCIx_LTR) is the first data byte. For RX frames, it contains timeout bits 7–0.The time is specified in
multiples of bit times. The timeout period starts with the transmission of the LIN break character.
8–31 Reserved.
Table 21-12. ESCIx_LTR Tx Frame Fourth+ Byte/
Rx Frame Fifth+ Byte Field Description
Field Description
0–7
Dn
Data bits for transmission.
8–31 Reserved.
Table 21-10. ESCIx_LTR Third-Byte Field Descriptions (continued)
Field Description
