Refer to Table 6-19 for bit field definitions. Table 6-64 lists the PA fields for PCSA[2]_SCKD_GPIO[98].
6.3.1.65 Pad Configuration Register 99 (SIU_PCR99)
The SIU_PCR99 register controls the function, direction, and electrical attributes of
PCSA[3]_SIND_GPIO[99]. This register allows selection of the PCSA[3], SIND and GPIO functions.
Figure 6-66. PCSA[3]_SIND_GPIO[99] Pad Configuration Register (SIU_PCR99)
Refer to Table 6-19 for bit field definitions. Table 6-65 lists the PA fields for PCSA[3]_SIND_GPIO[99].
Table 6-64. PCR98 PA Field Definitions
PA Field Pin Function
0b00 GPIO[98]
0b01 PCSA[2]
0b10 SCKD
0b11 PCSA[2]
Address: Base + 0x0106 Access: R/W
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R 0 0 0 0
PA OBE
1
1
When configured as PCSA[3] or SIND, the OBE bit has no effect. When configured as GPDO, set the OBE bit to 1.
IBE
2
2
When the pad is configured as an output, set the IBE bit to 1 to show the pin state in the GPDI register.
Clear the IBE bit to 0 to reduce power consumption. When configured as GPDI, set the IBE bit to 1.
0 0
ODE HYS SRC WPE WPS
W
RESET: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1
Table 6-65. PCR99 PA Field Definitions
PA Field Pin Function
0b00 GPIO[99]
0b01 PCSA[3]
0b10 SIND
0b11 PCSA[3]
