System Integration Unit (SIU)
MPC5566 Microcontroller Reference Manual, Rev. 2
6-52 Freescale Semiconductor
6.3.1.60 Pad Configuration Register 94 (SIU_PCR94)
The SIU_PCR94 register controls the function, direction, and electrical attributes of
SINA_PCSC[2]_GPIO[94]. This register allows selection of the SINA, PCSC[2] and GPIO functions.
Figure 6-61. SINA_PCSC[2]_GPIO[94] Pad Configuration Register (SIU_PCR94)
Refer to Table 6-19 for bit field definitions. Table 6-60 lists the PA fields for SINA_PCSC[2]_GPIO[94].
6.3.1.61 Pad Configuration Register 95 (SIU_PCR95)
The SIU_PCR95 register controls the function, direction, and electrical attributes of
SOUTA_PCSC[5]_GPIO[95]. This register allows selection of the SOUTA, PCSC[5] and GPIO[95]
functions.
Figure 6-62. SOUTA_PCSC[5]_GPIO[95] Pad Configuration Register (SIU_PCR95)
Address: Base + 0x00FC Access: R/W
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R 0 0 0 0
PA
1
1
The SINA function is available on the MPC5566 only.
OBE
2
2
When configured as SINA or PCSC[2], the OBE bit has no effect. When configured as GPDO, set the OBE bit to 1.
IBE
3
3
When the pad is configured as an output, set the IBE bit to 1 to show the pin state in the GPDI register.
Clear the IBE bit to 0 to reduce power consumption. When configured as GPDI, set the IBE bit to 1.
0 0
ODE HYS SRC WPE WPS
W
RESET: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1
Table 6-60. PCR94 PA Field Definitions
PA Field Pin Function
0b00 GPIO[94]
0b01 SINA
0b10 PCSC[2]
0b11 SINA
Address: Base + 0x00FE Access: R/W
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R 0 0 0 0
PA
1
1
The SOUTA function is available on the MPC5566 only.
OBE
2
2
When configured as SOUTA or PCSC[5], the OBE bit has no effect. When configured as GPDO, set the OBE bit to 1.
IBE
3
3
When the pad is configured as an output, set the IBE bit to 1 to show the pin state in the GPDI register.
Clear the IBE bit to 0 to reduce power consumption. When configured as GPDI, set the IBE bit to 1.
0 0
ODE HYS SRC WPE WPS
W
RESET: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1
