System Integration Unit (SIU)
MPC5566 Microcontroller Reference Manual, Rev. 2
6-56 Freescale Semiconductor
6.3.1.66 Pad Configuration Register 100 (SIU_PCR100)
The SIU_PCR100 register controls the function, direction, and electrical attributes of
PCSA[4]_SOUTD_GPIO[100]. This register allows selection of the PCSA[4], SOUTD, and GPIO
functions.
Figure 6-67. PCSA[4]_SOUTD_GPIO[100] Pad Configuration Register (SIU_PCR100)
Refer to Table 6-19 for bit field definitions. Table 6-66 lists the PA fields for
PCSA[4]_SOUTD_GPIO[100].
6.3.1.67 Pad Configuration Registers 101 (SIU_PCR101)
The SIU_PCR101 register controls the function, direction, and electrical attributes of
PCSA[5]_PCSB[3]_GPIO[101]. This register allows selection of the PCSA[5], PCSB[3] and GPIO
functions.
Figure 6-68. PCSA[5]_PCSB[3]_GPIO[101] Pad Configuration Register (SIU_PCR101)
Address: Base + 0x0108 Access: R/W
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R 0 0 0 0
PA
1
1
The PCSA[4] function is available on the MPC5566 only.
OBE
2
2
When configured as PCSA[4] or SOUTD, the OBE bit has no effect. When configured as GPDO, set the OBE to 1.
IBE
3
3
When PCSA[4] or SOUTD is configured for slave operation, set the IBE bit to 1. When the pad is configured as an output, set
the IBE bit to 1 to show the pin state in the GPDI register. Clear the IBE bit to 0 to reduce power consumption. When configured
as GPDI, set the IBE bit to 1.
0 0
ODE HYS SRC WPE WPS
W
RESET: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1
Table 6-66. PCR100 PA Field Definitions
PA Field Pin Function
0b00 GPIO[100]
0b01 PCSA[4]
0b10 SOUTD
0b11 PCSA[4]
Address: Base + 0x010A Access: R/W
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R 0 0 0 0
PA
1
1
The PCSA[5] function is available on the MPC5566 only.
OBE
2
2
When configured as PCSA[5] or PCSB[3], the OBE bit has no effect. When configured as GPDO, set the OBE bit to 1.
IBE
3
3
When the pad is configured as an output, set the IBE bit to 1 to show the pin state in the GPDI register. Clear the IBE bit to 0
to reduce power consumption. When configured as GPDI, set the IBE bit to 1.
0 0
ODE HYS SRC WPE WPS
W
RESET: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1
