System Integration Unit (SIU)
MPC5566 Microcontroller Reference Manual, Rev. 2
6-60 Freescale Semiconductor
6.3.1.72 Pad Configuration Register 106 (SIU_PCR106)
The SIU_PCR106 register controls the function, direction, and electrical attributes of
PCSB[1]_PCSD[0]_GPIO[106].
Figure 6-73. PCSB[1]_PCSD[0]_GPIO[106] Pad Configuration Register (SIU_PCR106)
Refer to Table 6-19 for bit field definitions. Table 6-72 lists the PA fields for
PCSB[1]_PCSD[0]_GPIO[106].
6.3.1.73 Pad Configuration Register 107 (SIU_PCR107)
The SIU_PCR107 register controls the function, direction, and electrical attributes of
PCSB[2]_SOUTC_GPIO[107].
Figure 6-74. PCSB[2]_SOUTC_GPIO[107] Pad Configuration Register (SIU_PCR107)
Address: Base + 0x0114 Access: R/W
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R 0 0 0 0
PA OBE
1
1
When configured as PCSD[0], set the OBE bit to 1 for master operation, or clear to 0 for slave operation.
When configured as PCSB[1], the OBE bit has no effect. When configured as GPDO, set the OBE bit to 1.
IBE
2
2
When configured as PCSD[0] in slave operation, set the IBE bit to 1. When the pad is configured as an output, set the IBE bit
to 1 to show the pin state in the GPDI register. Clear the IBE bit to 0 to reduce power consumption. When configured as GPDI,
set the IBE bit to 1.
0 0
ODE HYS SRC WPE WPS
W
RESET: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1
Table 6-72. PCR106 PA Field Definitions
PA Field Pin Function
0b00 GPIO[106]
0b01 PCSB[1]
0b10 PCSD[0]
0b11 PCSB[1]
Address: Base + 0x0116 Access: R/W
0 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15
R 0 0 0 0
PA OBE
1
1
When configured as PCSB[2] or SOUTC, the OBE bit has no effect. When configured as GPDO, set the OBE bit to 1.
IBE
2
2
When the pad is configured as an output, set the IBE bit to 1 to show the pin state in the GPDI register. Clear the IBE bit to 0
to reduce power consumption. When configured as GPDI, set the IBE bit to 1.
0 0
ODE HYS SRC WPE WPS
W
RESET: 0 0 0 0 0 0 0 0 0 0 0 0 0 0 1 1
