Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
72 Checking the Repository Connection
Figure 68: Repository Settings Table
If no repositories have been configured, add repositories as needed. For more information, refer to
Section 3.12.5.3, “Adding a Repository”.
Section 3.12.5.2
Checking the Repository Connection
To check the connection with a repository, do the following:
1. Navigate to admin » software-upgrade » apps and click check-repository-connection in the menu. The
Check Repository Connection and Trigger Action forms appear.
Figure 69: Check Repository Connection Form
1. App Name Box
Figure 70: Trigger Action Form
1. Perform Button
2. On the Check Repository Connection form, configure the following parameters:
