Chapter 3
Device Management
RUGGEDCOM ROX II
User Guide
58 Upgrading/Downgrading the ROX II Software
Figure 51: Load Full Configuration
1. Format List 2. Filename Box
Figure 52: Trigger Action
1. Perform Button
2. On the Load Full Configuration form, configure the following parameters:
Parameter Description
format Synopsis: cli
Load a full configuration from a file
file-name
3. On the Trigger Action form, click Perform.
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
Section 3.11
Upgrading/Downgrading the ROX II Software
The following sections describe how to upgrade and downgrade the ROX II software:
• Section 3.11.1, “Configuring the Upgrade Source”
• Section 3.11.2, “Setting Up an Upgrade Server”
