RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Deleting a Zone 377
Parameter Description
Name A unique name to assign to this zone. Be sure to also create a zone called fw that is of
the zone type firewall.
5. Click Add. The Firewall Zone form appears.
Figure 410: Firewall Zone Form
1. Type List 2. Description Box
6. Configure the following parameter(s) as required:
Parameter Description
Type Synopsis: ipv4, ipsec, firewall
Default: ipv4
Zone types are firewall, IPv4 or IPSsec
description (Optional) The description string for this zone
7. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
8. Click Exit Transaction or continue making changes.
Section 5.17.8.3
Deleting a Zone
To delete a zone, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to security » firewall » fwconfig » {firewall} » fwzone, where {firewall} is the name of the firewall.
The Firewall Zone table appears.
