RUGGEDCOM ROX II
User Guide
Chapter 5
Setup and Configuration
Viewing a List of LSP Generation Intervals 421
• Section 5.18.6.2, “Adding an LSP Generation Interval”
• Section 5.18.6.3, “Deleting an LSP Generation Interval”
Section 5.18.6.1
Viewing a List of LSP Generation Intervals
To view a list of LSP generation intervals configured for an IS-IS area, navigate to routing » dynamic » isis »
area » {name} » lsp-gen-interval, where {name} is the unique name for a routing process that belongs to a
specific router. If intervals have been configured, the LSP Generic Interval Routing Type table appears.
Figure 459: LSP Generic Interval Routing Type Table
If no intervals have been configured, add intervals as needed. For more information, refer to Section 5.18.6.2,
“Adding an LSP Generation Interval”.
Section 5.18.6.2
Adding an LSP Generation Interval
To add an LSP generation interval to an IS-IS area, do the following:
1. Navigate to routing » dynamic » isis » area » {name} » lsp-gen-interval, where {name} is the unique
name for a routing process that belongs to a specific router.
2. Click <Add is-type>. The Key Settings form appears.
Figure 460: Key Settings Form
1. Routing Type List 2. Add Button
3. Configure the following parameter(s) as required:
Parameter Description
Routing Type Synopsis: level-1-only, level-2-only, level-1-2
