472 Adding an Aggregate Address Option
Figure 532: Aggregate Network Options Table
If no options have been configured, add options as needed. For more information, refer to Section 5.19.10.2,
“Adding an Aggregate Address Option”.
Section 5.19.10.2
Adding an Aggregate Address Option
To add an option for an aggregate address, do the following:
1. Change the mode to Edit Private or Edit Exclusive.
2. Navigate to routing » dynamic » bgp » aggregate-address » {address} » options, where {address} is the
subnet address and prefix for the aggregate address.
3. Click <Add options>. The Key Settings form appears.
Figure 533: Key Settings Form
1. Value List 2. Add Button
4. Configure the following parameter(s) as required:
Parameter Description
value Synopsis: as-set, summary-only
Aggregate address option.
5. Click Add to add the option.
6. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
7. Click Exit Transaction or continue making changes.
