Chapter 4
System Administration
RUGGEDCOM ROX II
User Guide
218 Managing Users
Figure 231: Secondary Radius Server Form
1. Address Box 2. Port UDP Box 3. Password Box
3. In both forms, configure the following parameters as required:
Parameter Description
address The IPv4 address of the server.
UDP Port Default: 1812
The IPv4 port of the server.
password Synopsis: The aes-cfb-128-encrypted-string works exactly like des3-cbc-encrypted-
string but AES/128bits in CFB mode is used to encrypt the string. The prefix for
encrypted values is '$4$'.
The password of the server
4. Click Commit to save the changes or click Revert All to abort. A confirmation dialog box appears. Click OK
to proceed.
5. Click Exit Transaction or continue making changes.
Section 4.9
Managing Users
ROX II allows for up to three user profiles to be configured locally on the device. Each profile corresponds to one
of the following access levels:
• Guest
• Operator
• Admin
The access levels provide or restrict the user's ability to change settings and execute various commands.
